OH1/OH2
Horizontal overhung pumps
OH1 uses a foot-mounted casing; OH2 uses a centerline-mounted casing. Both are horizontal, single-stage arrangements.
Design and equipment
API 610 pumps for industrial processes
Selection of pumps and spare parts taking into account the working environment, operating mode and project requirements. The main parameters and equipment are agreed upon according to the technical specifications.
Overhung Pumps
Single-stage arrangements with the impeller overhung from its support.
OH3/OH4
Vertical in-line pumps
OH3 uses a separate bearing housing and flexible coupling. OH4 uses a rigid coupling in a vertical in-line arrangement.
Between Bearings Pumps
The rotating assembly is supported by bearings on both sides.
BB1
Axially split pumps
One- or two-stage between-bearings pumps with an axially split casing. Explore the existing double-suction pump range.
BB3
Axially split multistage pumps
Multiple stages are arranged between the bearings within an axially split casing.
BB4
Ring-section multistage pumps
A single-casing, radially split multistage arrangement built from individual ring sections.
BB5
Barrel multistage pumps
A double-casing, radially split multistage arrangement with the inner assembly enclosed by an outer barrel.
Vertically Suspended Pumps
Vertical configurations for sump, wet-pit and can installations.
VS2
Vertical volute pumps
A vertically suspended, single-casing arrangement with a volute hydraulic section and discharge through the column.
VS4/VS5
Vertical suspended pumps
VS4 uses line-shaft bearings. VS5 uses a cantilever shaft without submerged shaft bearings. Both use a separate discharge line.
VS1/VS6
Vertical diffuser pumps
VS1 is a single-casing wet-pit arrangement. VS6 adds an outer can to form a double-casing arrangement; both use diffuser hydraulics.
Send us your inquiry
Please share your detailed technical requirements with us for review.
